YY2 - Industrial Patrol & Thermal Inspection UAV
YY2 is an industrial patrol and thermal inspection UAV designed for stable monitoring operations. It combines 30-40 minute endurance, GPS-RTK positioning, and a 3-axis gimbal with optical zoom and thermal measurement capability for reliable field inspection workflows.
Key Features
- Industrial patrol and thermal inspection workflow support
- 30-40 minute endurance for extended monitoring missions
- GPS-RTK positioning for stable route repeatability
- 3-axis stabilized gimbal for smooth observation output
- 30x optical zoom plus thermal measurement capability
- Target lock support for precision tracking operations
Product Overview
YY2 is an industrial patrol and thermal inspection UAV designed for stable monitoring operations. It combines 30-40 minute endurance, GPS-RTK positioning, and a 3-axis gimbal with optical zoom and thermal measurement capability for reliable field inspection workflows.
Technical Specifications
Dimensions & Structure
Wheelbase
1700mm
Folded Dimensions
1963 x 1700 x 670mm
Airframe Type
Hexacopter (6-rotor)
Propeller Size
34in
Weight & Payload
Empty Weight
15kg
Max Payload
5kg
Flight Performance
Flight Speed
10-15m/s
Max Flight Altitude
500m
Endurance
30-40min
Power & Navigation
Power Battery
14S / 30000mAh
Positioning Module
GPS-RTK
Max Control Range
10km
EO/IR Payload
Gimbal
3-axis stabilized gimbal (yaw, pitch, roll)
EO Sensor
30x optical zoom, 4.8-149 mm (±5%), 1/2.7-inch CMOS, 8 MP
Thermal Modes
Global, spot, and area temperature measurement
Target Lock
Supported
Application Scenarios
Primary Use Cases
Patrol, Inspection
Related Products
Explore related products in the Industrial Security Patrol UAVs range to compare deployment form factors, response methods, and system integration options for similar project requirements.
Counter-Drone Systems
Heavy-Lift Cargo UAVs
Heavy-Lift Cargo UAVsIY-240 Heavy-Lift Multirotor Cargo UAV
The IY-240 is a heavy-lift multirotor cargo UA...
168 kg Payload
Counter-Drone SystemsLM065 Multi-Function Radar
The LM065 Multi-Function Radar is designed for...
FPV DronesCustom FPV Drone Series
The Custom FPV Drone Series is designed for cu...
Firefighting Drones
Agriculture UAV DronesY6-60
Y6-60 is a heavy-payload agricultural UAV plat...
Counter-Drone SystemsPA450 Four-Side Phased Array Radar
The PA450 Four-Side Phased Array Radar is desi...
Explore Related Categories
Browse adjacent product categories to find complementary platforms, alternative configurations, and broader solution paths connected to this product line.
Industrial Security Patrol UAVs
Industrial security patrol UAVs for perimeter surveillance, alarm verification, and real-time aerial visibility across warehouses, industrial parks, energy sites, and large compounds.
Counter-Drone Systems
Counter-drone systems for airports, critical infrastructure, industrial facilities, and public security projects, covering detection, tracking, identification, and authorized response workflows.
Heavy-Lift Cargo UAVs
Heavy-lift cargo UAVs for industrial logistics, remote delivery, and mission-based aerial transport across construction, energy, emergency, and field operations.
FPV Drones
FPV drones for training, testing, custom integration, and configurable first-person flight projects with low-latency control and flexible setup options.
Firefighting Drones
Firefighting drones for thermal monitoring, hotspot detection, scene visibility, and emergency-response support across wildfire, urban, and industrial fire operations.
Agriculture UAV Drones
Agriculture UAV drones for spraying, spreading, crop protection, and precision farm operations across commercial field, orchard, and plantation environments.
Defense & Tactical UAVs
Mission-ready tactical UAV platforms for reconnaissance, surveillance, border patrol, and specialized payload operations in complex environments.
Frequently Asked Questions
What operating scenarios is YY2 best suited for?
YY2 is designed for industrial patrol and inspection missions, including perimeter security patrols, asset condition checks, thermal anomaly screening, and routine compliance monitoring workflows.
Is 30-40 minutes of endurance sufficient for real inspection operations?
Yes. For patrol and inspection tasks, 30-40 minutes typically supports efficient route coverage per sortie. With route segmentation and battery rotation, teams can maintain continuous mission throughput.
How strong are YY2 visual and thermal inspection capabilities?
YY2 supports 30x optical zoom and multiple thermal measurement modes (global, spot, and area), enabling both long-range visual identification and temperature-based anomaly detection in one workflow.
What practical value does GPS-RTK provide?
GPS-RTK improves route repeatability and positioning consistency, which is critical for fixed-point reinspection, trend comparison, and standardized inspection procedures.
How should we interpret the 10 km control range in real deployment?
The 10 km figure is system capability under suitable conditions. Effective field range depends on terrain shielding, electromagnetic interference, and regulatory limits, so mission planning should be based on real site conditions.
How are pricing and international delivery terms handled?
YY2 is offered on an inquiry basis, with pricing determined by payload setup, accessories, and destination requirements. We support FOB and CIF terms. DDP door-to-door service is not included in our standard trade scope.
